24V SPDT Relay Y90-SS-136D T90-1C-24V-5P – 5-Pin Relay

Description

The Y90-SS-136D T90-1C-24V-5P is a general-purpose power relay. Here’s a breakdown of its specifications based on standard naming conventions and available data for such relays:

Key Details:

1. Model: Y90-SS-136D
2. Series: T90
3. Coil Voltage: 24V DC (operates with a 24V DC supply for the relay coil).
4. Configuration: 1C (Single Pole Double Throw – SPDT).
5. Pins: 5P (5 pins, including coil and contact terminals).

Typical Features:

• Contact Capacity: Often rated for high-power loads like 10A to 30A at 250VAC or 30VDC.
• Coil Power Consumption: Typically low power, suitable for DC control circuits.
• Applications: Used in home appliances, automotive circuits, industrial control panels, and general switching applications.

Pinout (Generic SPDT Relay):

1. Coil Terminals (2 pins): For energizing the relay.
2. Common (COM): Central connection for the load.
3. Normally Open (NO): Connected to COM when the coil is energized.
4. Normally Closed (NC): Connected to COM when the coil is not energized.
