Description
A1015 PNP transistor is mainly designed to use as an audio amplifier or in audio amplification stages. The max collector to emitter voltage of the transistor is 50V therefore it can easily be used in circuits operating under 50V. For good performance it is recommended to use the transistor in circuits operating under 40V DC. The max collector dissipation of the transistor is 400mW and max DC current gain is 400 which makes this transistor a better device for small audio amplification. Moreover it can also be used as a switch and it can handle 150mA of load.
Features
- Package Type: TO-92
- Transistor Type: PNP
- Max Collector Current(IC): -150mA
- Max Collector-Emitter Voltage (VCE): -50V
- Max Collector-Base Voltage (VCB): -50V
- Max Emitter-Base Voltage (VEBO): -5V
- Max Collector Dissipation (Pc): 400 miliWatt
- Max Transition Frequency (fT): 80 MHz
- Minimum & Maximum DC Current Gain (hFE): 70 – 400
- Max Storage & Operating temperature Should Be: -65 to +150 Centigrade
Applications
Audio Preamplifiers Circuits
Audio Amplifier Circuits
Audio amplification Stages
Switching Loads under 150mA
How to Safely Long Run in a Circuit
To get long term and stable performance from this transistor in your circuits always stay under its maximum specification values like do not drive load more than 150mA, do not operate load more than 50V DC (for good performance stay below 40V DC). Always use a suitable base resistor. A base resistor limits the extra amount of current going into the base of the transistor. always operate the transistor under 125 Celsius and store it in temperature above -65 Celsius and and below +150 Celsius.
